General characteristics
| Saw frame | Double column |
| Band dimensions | 3270x27x0,9 mm |
| Band speed | 40/80 m/min |
| Cutting capacity 0° round | 300 mm |
| Cutting capacity 0° square | 300 mm |
| Cutting capacity 0° flat | 350x260 mm |
| Cutting capacity 45° | rund 210 mm, quadrat 210 mm, rechteck 210 x 260 mm |
| Cutting capacity 60° | rund 110 mm, quadrat 110 mm, rechteck 110 x 150 mm |
| Working height | 830 mm |
| Motor | 1.5 kW |
Dimensions and weight
| Length | 1500 mm |
| Width | 1600 mm |
| Height | 1900 mm |
| Weight | 590 kg |
Description
hydraulic vice incl. adjustable clamping pressure
saw beam moves up and down by hydraulic cylinder
fast descent
automatic fast up/down conrolled by feeler pin
adjustable pressure according to section and type of material
double safety buton for cycle start
2 speeds
coolant equipment
CUTTING CYCLE
Vice locking; Quick bow pull-down hydraulically operated; Blade rotation and cooling liquid start-up;
Working pull-down; end of the cutting cycle; Stop of blade rotation and supply of cooling liquid;
Quick bow lift-up; Stop of bow upwards movement; vice unlocking if selected.
Options:
Roller tables and band saw blades on request
